SG3524 Regulating Pulse Width Modulator IC DIP-16 Package

SG3524 incorporate all the functions required in the construction of a regulating power supply, inverter, or switching regulator on a single chip. It can be used as the control element for high-power-output applications. SG3524 was designed for switching regulators of either polarity, transformer-coupled dc-to-dc converters, transformerless voltage doublers, and polarity-converter applications employing fixed-frequency, pulse-width modulation (PWM) techniques. The complementary output allows either single-ended or push-pull application. Each device includes an on-chip regulator, error amplifier, programmable oscillator, pulse-steering flip-flop, two uncommitted pass transistors, a high-gain comparator, and current-limiting and shutdown circuitry. Features:- Complete Pulse-Width Modulation (PWM) Power-Control Circuitry Uncommitted Outputs for Single-Ended or Push-Pull Applications 8 mA (TYP) Standby Current Specification:- Parameter Value Part number SG3524 Topology Boost, Buck, Flyback, Forward, Full-Bridge, Half-Bridge, Push-Pull Control method Voltage VCC(Min) (V) 8 VCC(Max) (V) 40 Frequency(Max)(kHz) 722 UVLO thresholds on/off(V) Duty cycle(Max)(%) 45 Gate drive (Typ) (A) 0.05 Features Adjustable Switching Frequency, Error Amplifier, Multi-topology Rating Refer Data Sheet Operating temperature range (?C) 0 to 70 Package Group PDIP|16 Package size: mm2:W x L (PKG) 16PDIP: 181 mm2: 9.4 x 19.3 (PDIP|16) Related Document:- SG3524 IC Datasheet * Product Images are shown for illustrative purposes only and may differ from actual product.
